Product Name

501302 Steel Riser Clamp For Copper Tubing

Model Number

Download Link
Parameter
Features
  • Connection Flange
  • Structure Vertical
  • Flexible or Rigid Rigid
  • Material Carbon Steel
  • Specification MSS SP-69 &SP-58,WW-H-171E
  • Transport Package Exported Package
  • Riser Pipe Clamp for For Vertical Copper Tube
  • Material: Carbon Steel
  • Size Range: 1/2" through 6"
  • Finish: Copper Colored Epoxy Plated
  • Comply with Federal Specification WW-H-171E and American Manufactures Standardization Society MSS SP-69 & SP58
· Riser Pipe Clamp for For Vertical Copper Tube
· Material: Carbon Steel
· Size Range: 1/2" through 6"
· Finish: Copper Colored Epoxy Plated
· Comply with Federal Specification WW-H-171E and American Manufactures Standardization Society MSS SP-69 & SP58
