Product Name

501912 Adjustable Pipe Support Assembly

Model Number

Download Link
Parameter
Features
  • Connection Flange
  • Structure Vertical
  • Flexible or Rigid Rigid
  • Material Carbon Steel
  • Transport Package Exported Package
  • Material: Carbon Steel
  • Finish: Zinc-plated
  • Size Range: 2-1/2" Through 36"
  • Supports Horizontal Pipe From Stanchions Where Vertical Adjustment is Needed
  • Comply with Federal Specification WW-H-171E and American Manufactures Standardization Society MSS SP-69 & SP58
•    Material: Carbon Steel
•    Finish: Zinc-plated
•    Size Range: 2-1/2" Through 36"
•    Supports Horizontal Pipe From Stanchions Where Vertical Adjustment is Needed
•    Comply with Federal Specification WW-H-171E and American Manufactures Standardization Society MSS SP-69 & SP58
